6-51mm Hydraulic Hose Crimping Machine with Fast Change Mould Tool and 10 Interchangeable Dies for Versatile Crimping

6-51mm Hydraulic Hose Crimping Machine with Fast Change Mould Tool and 10 Interchangeable Dies for Versatile Crimping

Marchio:	FY
Numero di modello:	FY-P38
MOQ:	1 set
prezzo:	USD$ 1850/1800/1750/1700
Condizioni di pagamento:	L/C,T/T,D/A,D/P,Western Union,MoneyGram
Capacità di approvvigionamento:	300 set al mese

Informazioni dettagliate

Descrizione del prodotto

Informazioni dettagliate

Luogo di origine:

La Cina, Shanghai

Certificazione:

Voltaggio:

220V/240V/380V/415V ((facoltativo)

Peso lordo:

300 kg

Peso netto:

275 kg

potenza (w):

3KW/4KW

Dimensione (l*w*h):

950*630*700 millimetro

Dimensione del pacchetto:

1000*680*750 millimetro

Garanzia:

1 anno

Condizione:

Nuovo

Servizio post-vendita fornito:

Supporto tecnico video, supporto online

Forza di crimpatura:

300Ton/0,3MT

Nome del prodotto:

Macchina per piegare tubi idraulici elettrici da 2 pollici fino a 2,5 pollici 6-51mm con strumento d

Gamma di crimpatura:

6-51 mm/1,5 pollici/2 pollici

Colore:

Blu, blu o personalizzato

applicazione:

Crimpaiolo

Stampi gratuiti:

10 set

Pressione del sistema:

26MPa/31.5MPa/260 bar/315 bar

Volume di uscita della pompa:

2.5L/5L

Evidenziare:

Macchina di piegatura del tubo idraulico avanzato, macchina di piegatura del tubo idraulico di contr

Imballaggi particolari:

SCATOLA IN LEGNO

Capacità di alimentazione:

300 set al mese

Evidenziare:

6-51mm Crimping Range Hydraulic Hose Crimping Machine

Fast Change Mould Tool Hose Crimper

10 Interchangeable Dies Hydraulic Crimper

Descrizione del prodotto

2 Inch Electric Hydraulic Hose Crimping Machine

Introducing the 2 Inch Electric Hydraulic Hose Crimping Machine, a versatile and efficient tool designed for precision crimping in hydraulic applications. This advanced machine can handle hoses up to 2.5 inches in diameter and features a crimping range of 6mm to 51mm. Equipped with a fast change mould tool and 10 interchangeable dies, this machine is ideal for hydraulic repair shops, automotive service centers, and oil industries in the USA, Europe, and Southeast Asia.

Key Features

Versatile Crimping Capacity: Capable of crimping hoses ranging from 6mm to 51mm, suitable for multiple applications
Fast Change Mould Tool: Innovative design minimizes downtime with quick and hassle-free die adjustments
Electric Power Operation: Consistent hydraulic system delivers reliable performance under various working conditions
10 Interchangeable Dies: Flexible handling of different hose sizes for diverse tasks
Durable Construction: High-quality materials ensure long-lasting performance in demanding environments

Operational Advantages

Increased Efficiency: Quick die changes and electric operation enhance workshop productivity
Cost-Effective Solution: Accommodates multiple hose sizes, reducing equipment and maintenance costs
User-Friendly Design: Intuitive controls and fast change features suitable for technicians of all skill levels
Reliable Performance: Engineered for durability with consistent, secure crimping results
Wide Applicability: Ideal for hydraulic repair shops, automotive facilities, and oil industries

Technical Specifications

Model	FY-P51 Hose Crimping Machine
Crimping Range	6-51mm (1/4"-2")
Crimping Force	300T
System Pressure	26Mpa/31.5Mpa (Optional)
Accuracy	0.01mm
Work Efficiency	200 pcs/h
Voltage Options	220V/240V/380V/415V
Motor Power	3KW/4KW
Dimensions (LWH)	950630700 mm
Weight	275kg
Die Sets Included	10 sets
